Logos Portable X-ray System EVRÝ system
- Product description: The EVRÝ system is a unique product that offers unparalleled versatility for all imaging environments. Compact enough for desktop use and rugged enough to be operated from the back of any vehicle, the
Product introduction
Brief
The EVRÝ system is a unique product that offers unparalleled versatility for all imaging environments. Compact enough for desktop use and rugged enough to be operated from the back of any vehicle, the EVRÝ gives portable x-ray users access to fast, high quality computed radiography imaging at an affordable price.
Highlight
Compact, Desktop, Sigle Plate Reader
25 Plates/hr (14” x 17”) , 60 Sec. to Image Display
Multiple Image Plate Size Options
Industry Leading Image Quality
Logos Software Platform
Technical Data
CR Reader Type：Compact Desktop Reader with Integrated Image Plate Eraser
Dimensions (H,W,D)：12.6” x 28.4” x 16.4”, (32 x 72.1 x 41.7 cm)
Interface Cable：USB 2.0 Cable
Electrical Voltage：100-240 VAC, 50/60 Hz, Auto-sensing
Power Consumption：110 W Max - 200 VA Max
Image Plate Size：14” x 17“ (35 x 43 cm)
Image Display Time：Standard Resolution: 90 seconds
High Resolution: 130 seconds
Throughput (with 120 sec erase / IP)： Standard Resolution: 15 plates / hour
High Resolution: 13 plates / hour
Resolution: Standard - 150 DPI (5.9 pixels/mm),169 micron square pixels, approximately 2.9 lp/mm
High - 300 DPI (11.8 pixels/mm), 85 micron square pixels, approximately 5.9 lp/mm
Pixel Depth:16 bits
Storage and Shipping: -40° to 122° F, (-40° to 50° C)
Environmental Operating Conditions： Temperature: 32° to 104° F, (0° to 40° C)
Relative Humidity: 5% to 95% RH, Non-condensing
Safety Standards： General: UL 60601-1 ( 2003), IEC 60601-1 (2005) CAN/CSA C22.2 No 601.1-M90
EMI: EN 60601-1-2 (2007) Group 1 Class A, IEC 60601-1-2 (2007) Group 1 Class A
Electrical: Class I (grounded)
Laser: IEC 60825-1 (2007) Class 1 Laser Device
