Logos portable, DR imaging system - NEOS

Product introduction

Brief

Logos Imaging's NEOS portable, Direct Radiography (DR) imaging system is a lightweight, man or robot deployable, EOD/IEDD portable x-ray solution. With its superb image resolution, wide image format, and fast image acquisition, the NEOS portable x-ray system is an ideal, cost-effective digital x-ray tool for your everyday imaging needs.

Weighing less than 15 pounds with the tripod mount, hot-swappable battery, and interface, the NEOS can be deployed by one person in less than five minutes. Once deployed, the NEOS hot-swappable battery system allows users to operate the system all day with no downtime even when 100/220V power isn't available.

Highlight

Wired and Wireless Operation Standard

Easily Attaches to a Tripod with Standard Equipment

High Image Resolution, 127μm Pixel Size

Compatible with All 5 Pin Golden Engineering Sources

Logos Software Platform

Greater than 60mm Penetration in Steel using the XRS-3

Technical Data

Detector Type: Amorphous Silicon, CsI:TI

Detecting Area: 10.4" x 12.8" (264 x 325 mm)

Pixel Resolution: 2,080 x 2,560 pixels

Pixel Pitch: 127µm

Dynamic Range: Greater than 73dBµ

Pixel Depth: 14bits

Dimensions (Panel Only): 15.9" x 16.6" x 0.9" (403 x 422 x 23 mm)

Weight: 7.7 lbs (3.5 kg)
