VISQUETM InVivo Elite
SMART Real-Time Optical In Vivo Imaging System
VISQUE™InVivo Elite is an in vivo imaging device for preclinical phase, with combination of Viework's high performance industrial camera and incomparable technological competence in medical imaging solution.
Deploying TEC (Thermoelectric Peltier) cooling technology, high performance digital camera cools down camera sensor, as much as 20℃ lower than surrounding temperature. This cooling effect ensures stability in operation despite exposure for long hours, and thus enhances sensitivity of camera. With design to maximize thermo emission of the digital cooling camera and interior of the device, VISQUE™InVivo Elite minimizes noise in images and captures high quality images, maintaining high sensitivity despite long exposure.
Motor-controlled full HD zoom lens enables easy zooming in and out, opening and closing of aperture, and focusing with software tools. Thus it can offer high resolution images of at least 33㎛. VISQUE InVivo Elite issuitable for luminescent and fluorescent photography from visible rays to near infrared rays. Further, high-speed imaging reaching the maximum of 24 fps and patented mechanical design make real-time fluorescence imaging possible.
In addition, CleVue™, viewer software for VISQUE™ InVivo Elite, can offers analyzed images and ROI's statistics data for academic papers with analysis tools that has been developed by close and continuous collaboration with researchers.
VISQUE™InVivo Elite can be used for diverse purposes ranging from research activities on cancer,angiogenesis, liver function, neurology, inflammation disease, to stem cells, and further, analysis on bio functions of cardiovascular and lymphoid organs and pharmacokinetics.
Features
Noise removal
technology that does not
- High
performance digital camera that deployed TEC (Thermoelectric Cooling)
technology, with use of Peltier
Multi-wavelength
Fluorescence Imaging
- Automatic
multi-wavelength filter wheel
·Default
imaging mode: GFP, PE, Cy5.5, ICG
High-performance
Full HD Zoom Lens
-
High-performance 6x zoom (FOV: 280 x 210 mm ∼ 50 x 40 mm)
Patented
Multi-functional Analysis Program for Fluorescence and Luminescence Images
-
High-resolution images and statistics data that can be used for academic
papers
A Diverse
Range of Convenient Functions
-
Thermostat with temperature control function (Off, 25℃, 36℃)
require ultra cooling apparatus
-
High-sensitivity sensor and unparalleled capacity in camera circuit design
- Patented
design for thermal radiation of camera
- Software
algorithm for image noise removal
- Resolved
inconvenience related to ultra cooling apparatus including abrasion with use
and refilling of gas
-
High-speed imaging (maximum: 24 fps)
- Time
exposure available (maximum: 50 mins.)
- Easy
adjustment of lenses including aperture, focus and zoom with software tools
- ROI
radiance analysis, pseudo-color mapping
- Kinetics
analysis with time-lapse images (e.g. MTT, BFI)
- Touch
panel for easy control
- Stage
including fixing devices to fix heads of subjects including rats, and
anesthesia system (option)
- Marker to
mark center location of imaging subject
- Double
doors and foot switch lighting system and sliding stage for preconditioning
process to enable imaging
immediately
after injecting contrast media
Fluorescent Imaging Agents
- - GFP/ EGFP / Alexa448 / FITC/ Fluorescein (Ex: 440 - 490 nm, Em: 515 - 575 nm)
- - RFP/ DsRed/ PE/ Alexa 568/ mCherry (Ex: 500 - 545 nm, Em: 575 - 650 nm)
- - Cy5.5 / PKE680 / Alexa 660 (Ex: 620 - 650 nnm / 640 - 680 nm, Em: 700 - 770 nm)
- - ICG / QD800 (Ex: 760 - 780 nm, Em: 810 - 870 nm)
